Flexirol Sliding
For sliding wooden or metal doors weighing up to 500kg
SKU:
flexirol-sliding
Contact a member of our sales team to enquire about this product
| Product | Max Door Width | Door Thickness Range | Door Material | Application | Max Door Weight |
|---|---|---|---|---|---|
| Flexirol Sliding | 6000mm | 40 - 100mm | Wood/Metal | Interior/Exterior | 500kg |
| Document | Name | File size | |
|---|---|---|---|
|
Flexirol Sliding Brochure Page | 1.02 MB | Download |
|
|
P C Henderson Case Study- Flexirol Straight Sliding - Four Seasons Hotel | 3.55 MB | Download |
| Description | DXF | DWG |
|---|
106N 94 - GUIDE LVL A |
||||
| 106N 94 - GUIDE LVL A | 62.10 KB | 305.29 KB | 253.99 KB | |
94X - CHANNEL LVL A |
||||
| 94X - CHANNEL LVL A | 44.28 KB | 293.55 KB | 250.95 KB | |
104N 94 - GUIDE LVL A |
||||
| 104N 94 - GUIDE LVL A | 58.59 KB | 234.36 KB | ||
104NX 94 - GUIDE LVL A |
||||
| 104NX 94 - GUIDE LVL A | 63.48 KB | 352.17 KB | 266.37 KB | |
94T - TRESHOLD LVL A |
||||
| 94T - TRESHOLD LVL A | 78.40 KB | 325.99 KB | 159.15 KB | |
1A 550 - BRACKET LVL A |
||||
| 1A 550 - BRACKET LVL A | 66.64 KB | 406.35 KB | 279.91 KB | |
3S 550 - BRACKET LVL A |
||||
| 3S 550 - BRACKET LVL A | 57.85 KB | 443.63 KB | 288.25 KB | |
556 - HANGER LVL A |
||||
| 556 - HANGER LVL A | 71.53 KB | 493.28 KB | 304.63 KB | |
89 2N - GUIDE LVL A |
||||
| 89 2N - GUIDE LVL A | 73.57 KB | 2.28 MB | 761.92 KB | |
94 - CHANNEL LVL A |
||||
| 94 - CHANNEL LVL A | 44.23 KB | 293.64 KB | 250.93 KB | |
HH3 301 - STOP LVL A |
||||
| HH3 301 - STOP LVL A | 56.04 KB | 514.34 KB | 307.83 KB | |
550 - FLEXIROL STRAIGHT SLIDING STEEL LVL A |
||||
| 550 - FLEXIROL STRAIGHT SLIDING STEEL LVL A | 89.32 KB | 3.81 MB | 1.12 MB | |
550 - FLEXIROL STRAIGHT SLIDING TIMBER LVL A |
||||
| 550 - FLEXIROL STRAIGHT SLIDING TIMBER LVL A | 66.84 KB | 4.22 MB | 1.23 MB | |
556 52 - HANGER LVL A |
||||
| 556 52 - HANGER LVL A | 74.84 KB | 516.15 KB | 309.97 KB | |
556 57 - HANGER LVL A |
||||
| 556 57 - HANGER LVL A | 449.81 KB | 293.23 KB | ||
- For wooden or metal doors (either angle frame or box section) weighing up to 500kg
- Ideally suited for hotels, conference centres, shop fronts and showrooms which require high performance
- Track can be soffit fixed or face fixed for flexibility of installation
- Available with an optional suspended ceiling bracket (see datasheet for details)
Flexirol is a unique system ideally suited to large doors which require high performance as well as an attractive finish. It’s an ideal product for hotels, offices, conference centres, shop fronts and showrooms where durability and design are paramount. The product caters for wooden or metal doors fabricated from either angle frame or box section with aluminium extrusion. The track can be soffit fixed or face fixed for flexibility of installation.
More Information
| Fire Rated (Yes/No) | No |
|---|---|
| Max. Door Weight | 500kg |
| Max. Door Width | 6000mm |
| Door Type | Sliding Door |
| Door Material | Wood or Metal |
| Situation | Interior |
| Application | Residential/Commercial |
| Door Thickness Range | 40 - 100mm |
Q&A
Q&A
Question:
Does this product has a similar kit like SIM100 - Simultaneous Action Kit?
Question by: Jaime on 14 Feb 2021, 00:00
Answer:
Good afternoon,Unfortunately we do not have a simultaneous action kit for our Flexirol system.Many thanks,KateMarketing Executive
Answer by: admin admin (Admin) on 16 Feb 2021, 16:49
