Pocket Door Pro
Transform interiors with Pocket Door Pro, the professional-grade pocket door system designed for modern architectural spaces. By concealing the door neatly within the wall, it maximises usable floor space, enhances room flow, and delivers a sleek, minimalist finish without compromising on performance.
Designed for Heavyweight Doors
Designed to support internal doors weighing up to 120kg, making it ideal for large-format timber and premium interior doors.
Robust Aluminium Cavity Frame
The high-strength aluminium frame delivers exceptional rigidity, durability and long-term performance, even in demanding residential and commercial environments.
Premium Soft-Close Technology
Compatible with soft-close that gently slows the door at the end of its travel, creating a smooth, controlled and luxurious user experience.
Maximum Opening Space
The pocket door disappears completely into the wall cavity, freeing up valuable floor space and creating a clean, uncluttered interior.
Built for Professional Installers
Developed with installers in mind, Pocket Door Pro offers a precise, reliable solution for high-end projects where performance and finish are paramount.
Smooth & Quiet Operation
A premium aluminium track system and precision-engineered running gear ensure effortless and near-silent door movement.
-
Specifications
More Information SKU Pocket Door Pro Fire Rated (Yes/No) No Track Material Anodised Aluminium Location Internal Application Residential, Commercial Max. Door Weight 120kg Door Material Wood -
What comes in the box
- Aluminium track
- Aluminium uprights
- Hangers
- Fixing plate
- Clip top
- Noggins
- Floor/wall brackets
- Guide
- Track extension piece
- Space plates
- Soft close
- Liner kit
-
Product comparison
-
Pocket Door Learn more -
Pocket Door Pro Fire Rated Learn more
Show less
Feature Pocket Door Pro Pocket Door Pocket Door Pro Fire Rated Max. Door Weight 120kg 60kg 120kg Finished Wall Thickness 115, 120 and 125mm 120mm 145 and 150mm Soft Close? Yes Yes Yes Liner Kit? Yes Yes Yes Fire Rated? No No FD30 -
| Product Code | Max. Door Width | Max. Door Height | Door Material | Door Thickness Range | Max. Door Weight | Finished Wall Thickness |
|---|---|---|---|---|---|---|
| PDKPROH1 | 610mm | 1981mm | Wood | 35 – 45mm | 120kg | 120mm or 125mm |
| PDKPROH2 | 686mm | 1981mm | Wood | 35 – 45mm | 120kg | 120mm or 125mm |
| PDKPROH3 | 762mm | 1981mm | Wood | 35 – 45mm | 120kg | 120mm or 125mm |
| PDKPROH4 | 838mm | 1981mm | Wood | 35 – 45mm | 120kg | 120mm or 125mm |
| PDKPROH6 | 826mm | 2040mm | Wood | 35 – 45mm | 120kg | 120mm or 125mm |
| PDKPROH7 | 726mm | 2040mm | Wood | 35 – 45mm | 120kg | 120mm or 125mm |
| PDKPROH10 | 930mm | 2315mm | Wood | 35 – 45mm | 120kg | 120mm or 125mm |
| Document | Name | File size | |
|---|---|---|---|
|
Pocket Door Pro Data Sheet - Single Door | 1.24 MB | Download |
|
|
Pocket Door Pro Fitting Instructions | 4.14 MB | Download |
|
|
Pocket Door Pro Brochure Page | 1.08 MB | Download |
|
|
Pocket Door Pro Liner Kit Fitting Instructions - Single Doors | 586.49 KB | Download |
|
|
Pocket Door Pro Liner Kit Fitting Instructions - Bi-Parting Doors | 503.10 KB | Download |
|
|
Pocket Door Pro Data Sheet - Bi-Parting Doors | 1.21 MB | Download |
| Description | DXF | DWG |
|---|
PDKPROH1 - 1981 x 610mm - 120mm FWT |
||||
| PDKPROH1 - 1981 x 610mm - 120mm FWT | 502.85 KB | 9.25 MB | 936.03 KB | |
PDKPROH1 - 1981 x 610mm - 125mm FWT |
||||
| PDKPROH1 - 1981 x 610mm - 125mm FWT | 549.97 KB | 10.35 MB | 1.01 MB | |
PDKPROH2 - 1981 x 686mm - 120mm FWT |
||||
| PDKPROH2 - 1981 x 686mm - 120mm FWT | 519.00 KB | 9.27 MB | 937.57 KB | |
PDKPROH2 - 1981 x 686mm - 125mm FWT |
||||
| PDKPROH2 - 1981 x 686mm - 125mm FWT | 550.63 KB | 10.36 MB | 1.01 MB | |
PDKPROH3 - 1981 x 762mm - 120mm FWT |
||||
| PDKPROH3 - 1981 x 762mm - 120mm FWT | 519.46 KB | 9.26 MB | 932.68 KB | |
PDKPROH3 - 1981 x 762mm - 125mm FWT |
||||
| PDKPROH3 - 1981 x 762mm - 125mm FWT | 229.53 KB | 10.85 MB | 1.06 MB | |
PDKPROH4 - 1981 x 838mm - 120mm FWT |
||||
| PDKPROH4 - 1981 x 838mm - 120mm FWT | 207.12 KB | 9.28 MB | 939.68 KB | |
PDKPROH4 - 1981 x 838mm - 125mm FWT |
||||
| PDKPROH4 - 1981 x 838mm - 125mm FWT | 222.07 KB | 10.37 MB | 1.01 MB | |
PDKPROH6 - 2040 x 826mm - 120mm FWT |
||||
| PDKPROH6 - 2040 x 826mm - 120mm FWT | 223.07 KB | 10.32 MB | 1.01 MB | |
PDKPROH6 - 2040 x 826mm - 125mm FWT |
||||
| PDKPROH6 - 2040 x 826mm - 125mm FWT | 239.69 KB | 11.45 MB | 1.11 MB | |
PDKPROH7 - 2040 x 726mm - 120mm FWT |
||||
| PDKPROH7 - 2040 x 726mm - 120mm FWT | 222.04 KB | 10.31 MB | 1.01 MB | |
PDKPROH7 - 2040 x 726mm - 125mm FWT |
||||
| PDKPROH7 - 2040 x 726mm - 125mm FWT | 213.85 KB | 9.82 MB | 988.05 KB | |
PDKPROH10 - 2315 x 930mm - 120mm FWT |
||||
| PDKPROH10 - 2315 x 930mm - 120mm FWT | 329.51 KB | 16.56 MB | 1.60 MB | |
PDKPROH10 - 2315 x 930mm - 125mm FWT |
||||
| PDKPROH10 - 2315 x 930mm - 125mm FWT | 338.08 KB | 17.24 MB | 1.66 MB | |
Why Buy a Pocket Door?
Maximise floor space
Modern, minimalistic appearance
Ideal for bathrooms, bedrooms and offices
Improved accessibility
Flexible room layouts
What's in the Kit?
Anodised Aluminium Track
A high-quality aluminium track paired with durable nylon rollers delivers exceptionally smooth and quiet door operation. For easy access to the track and door after installation, we recommend creating a removable track insert section and connecting it to the main track using our track extension piece.
Aluminium Uprights
High quality aluminium cavity frame for enhanced longevity. The frame noggin securely clips to the uprights for easy and rapid installation.
Adjustable Clip Stop
Securely holds the door in the open position, allowing for ease access.
Dual Soft Close
Prevents slamming by gently slowing the door for a quieter, more premium experience.
Timber Liner Kit
Everything you need to neatly finish the opening, saving time on site and ensuring a high quality result.
Universal Floor Bracket
Universal floor bracket for varying finished wall thickness - 115mm, 120mm or 125mm.
Innovative Hanger
Designed with an innovative angled apron plate to allow for easy height adjustments of the door post installation.
Common Applications
Residential
Apartments
Healthcare
Hospitality
Education
Offices
FAQ's
Can the kit be cut down to suit non standard door sizes?
Yes - the kit can be cut down to size. Please see our fitting instructions for more information.
Can this kit be used for double pocket door applications?
Yes - for double pocket door applications, two kits should be purchased.
What is a liner kit?
The Pocket Door Liner Kit contains all the timber components needed to finish a pocket door opening quickly and professionally. Designed to fit the pocket door frame perfectly, it reduces on-site preparation time while delivering a clean, high-quality finish around the doorway.Do you offer a jamb kit?
Yes - our liner kit comes complete with pre-formed timber uprights and jamb to match the profile of our pocket door frame exactly. Available to suit 115mm, 120mm and 125mm finished wall thicknesses.
What is a dual soft close?
Dual soft close is a damper installed within the track to allow for the gentle open AND close of the door, preventing slamming.What is finished wall thickness and cavity thickness?
Cavity Thickness is the width of the pocket inside the wall where the door slides.
Finished Wall Thickness is the overall thickness of the completed wall after plasterboard and finishes have been applied.
What finished wall thickness does this kit cater for?
Finished Wall Thickness Cavity Thickness Plastboard 115mm 89mm 12.5mm plasterboard each side 120mm 95mm 12.5mm plasterboard each side 125mm 100mm 12.5mm plasterboard each side Do you offer a pocket door solution for doors larger than 2315mm x 930mm?
For doors over 2315mm x 930mm, we recommend installing our Husky 120 Pro and building your own stud work.
Opening Sizes
| Door Size | Single Doors | Bi-Parting Doors | ||
| Opening Size | Passage Size | Opening Size | Passage Size | |
| 1981mm x 610mm | 2046mm x 1250mm | 1966mm x 560mm | 2046mm x 2500mm | 1966mm x 1180mm |
| 1981mm x 686mm | 2046mm x 1402mm | 1966mm x 636mm | 2046mm x 2804mm | 1966mm x 1332mm |
| 1981mm x 762mm | 2046mm x 1554mm | 1966mm x 712mm | 2046mm x 3108mm | 1966mm x 1484mm |
| 1981mm x 838mm | 2046mm x 1706mm | 1966mm x 788mm | 2046mm x 3412mm | 1966mm x 1636mm |
| 2040mm x 826mm | 2105mm x 1682mm | 2025mm x 776mm | 2105mm x 3364mm | 2025mm x 1612mm |
| 2040mm x 726mm | 2105mm x 1482mm | 2025mm x 676mm | 2105mm x 2964mm | 2025mm x 1412mm |
| 2315mm x 930mm | 2380mm x 1890mm | 2300mm x 880mm | 2380mm x 3780mm | 2300mm x 1820mm |
More Information
| SKU | Pocket Door Pro |
|---|---|
| Fire Rated (Yes/No) | No |
| Track Material | Anodised Aluminium |
| Location | Internal |
| Application | Residential, Commercial |
| Max. Door Weight | 120kg |
| Door Material | Wood |
