Securefold Ultra

For wooden folding exterior doors weighing up to 100kg

Extremely weather and corrosion resistant - all components are made from 316 stainless steel

SKU:

securefold-ultra

Contact a member of our sales team to enquire about this product

Skip to the beginning of the images gallery

Product Information

Product	Max. Door Height	Max. Door Width	Door Thickness	Max. Door Weight	Door Material	Application
Securefold Ultra	3300mm	1000mm	48 - 68mm	100kg	Wood/Aluminium	Exterior

Documents

Attachments
Name	File size	PDF
Securefold R Loc Ultra Fitting Instructions	8.40 MB	Download
P C Henderson Securefold Brochure	6.89 MB	Download
Securefold Ultra Datasheet	922.71 KB	Download

CAD Drawings

Description	PDF	DXF	DWG

250 - TRACK LVL A
250 - TRACK LVL A	62.77 KB	324.16 KB	259.11 KB
94SC - CHANNEL LVL A
94SC - CHANNEL LVL A	26.64 KB	321.53 KB	153.93 KB
AQ21B Seal LVL A
AQ21B Seal LVL A	54.44 KB	321.04 KB	153.22 KB
AQ63B Seal LVL A
AQ63B Seal LVL A	51.53 KB	311.99 KB	150.66 KB
SF3 - HINGE SET LVL A
SF3 - HINGE SET LVL A	99.23 KB	3.30 MB	926.53 KB
SF7 - HINGE SET LVL A
SF7 - HINGE SET LVL A	110.09 KB	5.07 MB	1.34 MB
SF8 - ENDHANGER SET LVL A
SF8 - ENDHANGER SET LVL A	116.72 KB	1.12 MB	379.94 KB
SFU Securefold Ultra 100Kg Outward Opening 2+2 Leafs LVL A
SFU Securefold Ultra 100Kg Outward Opening 2+2 Leafs LVL A	309.24 KB		1.88 MB
SFU Securefold Ultra 100Kg Outward Opening 3+0 Leafs LVL A
SFU Securefold Ultra 100Kg Outward Opening 3+0 Leafs LVL A	141.54 KB		1.82 MB
SFU1 - PIVOT SET LVL A
SFU1 - PIVOT SET LVL A	78.48 KB	695.43 KB	256.09 KB
SFU2L - ENDHANGER SET LEFT LVL A
SFU2L - ENDHANGER SET LEFT LVL A	87.90 KB	753.19 KB	270.09 KB
SFU2R - ENDHANGER SET RIGHT LVL A
SFU2R - ENDHANGER SET RIGHT LVL A	91.65 KB	741.15 KB	267.71 KB
SFU4 - HANGER SET LVL A
SFU4 - HANGER SET LVL A	106.11 KB	2.67 MB	769.00 KB
SFU9 - PIVOT HINGE LVL A
SFU9 - PIVOT HINGE LVL A	76.64 KB	390.70 KB	176.66 KB

For wooden folding exterior doors weighing up to 100kg

For wooden and aluminium doors weighing up to 100kg
Enhanced security - tested to PAS24 and BS EN 1627 RC2
Extremely weather and corrosion resistant - all components are made from 316 stainless steel
Designed with a unique interlocking anti-tamper hinge, which makes it difficult to force out of position or dismantle
Three points of locking on every external door seam
Multipoint lock with anti-snap and anti-bump cylinder to withstand attack from even the most determined intruder
Available in four stunning finishes - satin, black, chrome and gold

Catering for wooden and aluminium doors weighing up to 100kg each, Securefold Ultra offers a superior system to our standard Securefold as it has been expertly designed to provide an additional level of security. The system can be specified in a number of different door configurations to suit your applications.

Enhanced Security

Securefold Ultra incorporates a number of enhanced components to make it one of the most secure bi-folding hardware systems on the market. It has been tested to both PAS 24 (UK) and BS EN 1627 RC2 (EU) security standards.

Extremely Corrosion Resistant

Designed and manufactured from 316 marine grade stainless steel, Securefold Ultra offers a robust system which is extremely weather and corrosion resistant, making the system ideal for coastal applications.

Four Stunning Finishes

Securefold Ultra is available in four stunning finishes – satin, black, gold and chrome – to match virtually any décor scheme.

R Loc

Securefold Ultra also includes the addition of R-Loc - a clever ratchet system that enables installers to easily raise or lower a door, eliminating the process of locking the hanger in place with a grub screw.

More Information

More Information
Fire Rated (Yes/No)	No

Q&A

Question:

On your cofold 100 r loc non mortise 100kg Doors are opening inwards where do you place the track in relation to the door is it central . Or dose the bottom bolt drop in to the track so I need to make a working sample . I realised that the top track is 19 mm off of central .

Question by: Kate Donkin on 22 Oct 2020, 01:00

Answer:

Good afternoon, We don 't actually do an inward opening for Securefold Ultra, so I 'm assuming your question should have been for our Securefold 100 product? If so - no the door is not central and you 're right in thinking that the bottom bolt drops into the track. Hope this helps - if you require any further information - please get in touch. Many thanks, Kate Marketing Assistant

Answer by: admin admin (Admin) on 22 Oct 2020, 16:18
