Soltaire Low Headroom
Sliding door kit for doors with restricted headroom weighing up to 180kg or 250kg
- Sliding door kit with vertical adjustment for low or restricted headroom applications
- Can reduce the clearance between the track and the top of the door to 2mm
| Short Code | Max. Door Width | Door Thickness Range | Max. Door Weight | Door Material | Application |
|---|---|---|---|---|---|
| LH180A | 3300mm | 35 -48mm | 180kg | Wood/Metal | Interior |
| LH250A | 3300mm | 35 - 48mm | 250kg | Wood/Metal | Interior |
| Document | Name | File size | |
|---|---|---|---|
|
Soltaire Low Headroom Fitting Instructions | 1.07 MB | Download |
|
|
Soltaire Low Headroom Datasheet | 667.78 KB | Download |
| Description | DXF | DWG |
|---|
94X - CHANNEL LVL A |
||||
| 94X - CHANNEL LVL A | 55.71 KB | 294.59 KB | 150.17 KB | |
1 SS - BRACKET LVL A |
||||
| 1 SS - BRACKET LVL A | 67.10 KB | 284.35 KB | ||
102SS 94 - GUIDE LVL A |
||||
| 102SS 94 - GUIDE LVL A | 69.19 KB | 272.90 KB | ||
106HSS 94 - GUIDE LVL A |
||||
| 106HSS 94 - GUIDE LVL A | 66.17 KB | 268.90 KB | ||
106SS 94 - GUIDE LVL A |
||||
| 106SS 94 - GUIDE LVL A | 61.60 KB | 269.12 KB | ||
180 - TRACK LVL A |
||||
| 180 - TRACK LVL A | 62.42 KB | 323.24 KB | 258.79 KB | |
250 - TRACK LVL A |
||||
| 250 - TRACK LVL A | 62.77 KB | 324.16 KB | 259.11 KB | |
LH180A - SOLTAIRE STRAIGHT SLIDING LOW HEADROOM LVL A |
||||
| LH180A - SOLTAIRE STRAIGHT SLIDING LOW HEADROOM LVL A | 41.51 KB | 2.06 MB | 655.26 KB | |
LH250A - SOLTAIRE STRAIGHT SLIDING LOW HEADROOM LVL A |
||||
| LH250A - SOLTAIRE STRAIGHT SLIDING LOW HEADROOM LVL A | 40.91 KB | 2.08 MB | 663.57 KB | |
- Caters for doors weighing up to 180kg and 250kg
- Sliding door kit with vertical adjustment for low or restricted headroom applications
- Can reduce the clearance between the track and the top of the door to 2mm
- Designed to create a modern, minimalist finish with all parts concealed within the track
- Track, guide, channel and brackets must be purchased in addition to kit
- Easy to install
Soltaire Low Headroom offers a superior sliding door kit for doors weighing up to 180kg and 250kg.
Ideal For Applications With Restricted Headroom
Ideal for applications with low or restricted headroom, the kit has been designed to reduce the clearance between the track and top of the door to 2mm – making the hardware barely visible.
Single or Biparting Doors
The system can cater for single sliding doors or two biparting doors on a single track. For double door applications, two kits can be purchased.
Specification
Track, guide, channel and brackets must be purchased in addition to this kit (depending on which kit you choose, please see accessories and spares). Please note: LH180A and LH250A are made to order, delivery date will be provided upon order confirmation.
More Information
| Fire Rated (Yes/No) | No |
|---|
