Stainless Steel

High performing sliding door gear suitable for areas exposed to extreme levels of corrosive elements.

For wooden and metal doors weighing up to 270kg
Ideal for marine areas, chemical plants and areas exposed to high levels of corrosion

SKU:

stainless-steel

Contact a member of our sales team to enquire about this product

Skip to the beginning of the images gallery

Product Information

Product	Door Thickness Range	Max. Door Weight	Door Material	Application
Stainless Steel 280	20mm - 50mm	100kg	Wood/Metal	Exterior
Stainless Steel 290	35mm - 48mm	150kg	Wood/Metal	Exterior
Stainless Steel 301	43mm - 57mm	270kg	Wood/Metal	Exterior

CAD Drawings

Description	PDF	DXF	DWG

89SS - CHANNEL LVL A
89SS - CHANNEL LVL A	26.38 KB	456.51 KB	125.70 KB
280SS - TRACK LVL B
280SS - TRACK LVL B	80.86 KB	379.83 KB	95.89 KB
281SS - BRACKET LVL A
281SS - BRACKET LVL A	47.50 KB	438.04 KB	137.36 KB
284NSS - HANGER LVL A
284NSS - HANGER LVL A	94.67 KB	902.76 KB	413.08 KB
284SS - HANGER LVL A
284SS - HANGER LVL A	84.40 KB	1.38 MB	279.13 KB
285NSS - HANGER LVL A
285NSS - HANGER LVL A	83.30 KB	855.58 KB	401.48 KB
285SS - HANGER LVL A
285SS - HANGER LVL A	83.06 KB	1.32 MB	273.73 KB
31SS - GUIDE LVL A
31SS - GUIDE LVL A	36.37 KB	720.18 KB	167.32 KB
3X 301SS
3X 301SS	39.23 KB		265.97 KB
4R 280SS - BRACKET LVL A
4R 280SS - BRACKET LVL A	31.51 KB	638.56 KB	151.44 KB
4RX 280SS - BRACKET LVL A
4RX 280SS - BRACKET LVL A	35.66 KB	689.33 KB	330.73 KB
53_290SS - LEVEL A
53_290SS - LEVEL A	136.76 KB		173.77 KB
56 301 SS - HANGER LVL A
56 301 SS - HANGER LVL A	97.06 KB	425.39 KB	179.99 KB

For wooden and metal doors weighing up to 270kg
Ideal for marine areas, chemical plants and areas exposed to high levels of corrosion
Extremely robust - components manufactured from high quality stainless steel
Can be soffit fixed or face fixed

Stainless Steel has been designed as a high performing sliding door system for wooden and metal doors weighing up to 270kg.

Extremely Corrosion Resistant
Manufactured from high quality stainless steel, the system offers a robust sliding door hardware solution for areas exposed to extreme levels of corrosive elements or where high levels of hygiene is required. Track, brackets and guide channel have been manufactured from 316(L) (A4) stainless steel and hanger components are made from nylon or 304(A2) grade stainless steel.

Ideal for Various Applications
Stainless Steel can be used in an array of applications such as chemical factories, oil rigs, abattoirs, cold storage, food processing plants and areas exposed to salt water.

Flexibility of Installation
The system is specified as individual components to suit varying door weights and environments. To allow for flexibility of installation, Stainless Steel can also be face fixed or soffit fixed to suit your application. Please Note: Fixing plates, bolts and nuts are Grade 304 (A2) Stainless Steel. The Stainless Steel range cannot be used with P C Henderson’s standard range of products.
