Tangent Folding

For top hung wooden or metal doors weighing up to 35kg, 55kg and 70kg

Doors can fold to one or both sides of the opening

SKU:

tangent-folding

Contact a member of our sales team to enquire about this product

Skip to the beginning of the images gallery

Product Information

Product	Max Door Height	Max Door Width	Door Thickness Range	Max Door Weight	Door Material	Application
Tangent 290	2400mm	900mm	35 - 50mm	35kg	Wood/Metal	Interior/Exterior
Tangent 301	3300mm	900mm	45 - 55mm	55kg	Wood/Metal	Interior/Exterior
Tangent 301H	3600mm	900mm	45 - 55mm	70kg	Wood/Metal	Interior/Exterior

Documents

Attachments
Name	File size	PDF
Tangent Folding 301 Quality Certificate	54.16 KB	Download
Tangent Folding 290 Datasheet	1.16 MB	Download
Tangent Folding 301 Datasheet	1.10 MB	Download

CAD Drawings

Description	PDF	DXF	DWG

89 - CHANNEL LVL A
89 - CHANNEL LVL A	110.52 KB	462.47 KB	665.22 KB
403 2 - HINGE LVL B
403 2 - HINGE LVL B	84.09 KB	608.26 KB	681.50 KB
1A 290 - BRACKET LVL A
1A 290 - BRACKET LVL A	53.36 KB	375.16 KB	273.99 KB
1A 301 - BRACKET LVL A
1A 301 - BRACKET LVL A	57.27 KB	430.05 KB	285.79 KB
290 - TANGENT FOLDING LVL A
290 - TANGENT FOLDING LVL A	108.05 KB	2.69 MB	813.24 KB
290 - TRACK LVL A
290 - TRACK LVL A	46.50 KB	325.05 KB	258.13 KB
301 - TRACK LVL A
301 - TRACK LVL A	116.14 KB		748.66 KB
301(H) - TANGENT FOLDING LVL A
301(H) - TANGENT FOLDING LVL A	130.03 KB	2.44 MB	718.26 KB
301H - TRACK LVL A
301H - TRACK LVL A	44.64 KB	334.94 KB	254.59 KB
3A 290 - BRACKET LVL A
3A 290 - BRACKET LVL A	22.35 KB	311.55 KB	99.01 KB
3A 301 - BRACKET LVL A
3A 301 - BRACKET LVL A	58.43 KB	363.48 KB	269.15 KB
62A - HANGER LVL B
62A - HANGER LVL B	108.13 KB	1.81 MB	1.09 MB
62K - HANGER LVL A
62K - HANGER LVL A	84.99 KB	1.72 MB	618.44 KB
63A - HANGER LVL A
63A - HANGER LVL A	71.56 KB	1.23 MB	495.30 KB
63K - HANGER LVL A
63K - HANGER LVL A	71.56 KB	1.26 MB	501.61 KB
65 - HINGE LVL A
65 - HINGE LVL A	65.70 KB	773.92 KB	369.90 KB
67 89 - GUIDE LVL A
67 89 - GUIDE LVL A	79.40 KB	1.29 MB	510.56 KB
67 97 - GUIDE LVL A
67 97 - GUIDE LVL A	79.30 KB	1.26 MB	502.71 KB
68 89 - GUIDE LVL A
68 89 - GUIDE LVL A	65.16 KB	761.90 KB	371.04 KB
68 97 - GUIDE LVL A
68 97 - GUIDE LVL A	66.43 KB	816.85 KB	385.81 KB
97 - CHANNEL LVL A
97 - CHANNEL LVL A	44.89 KB	294.85 KB	251.70 KB

Doors can fold to one or both sides of the opening
Any number of folding doors can be used to cover an opening
Three systems available to cater for doors weighing up to 70kg
Floating units should consist of an even number of leaves in units of four, six or eight

Tangent Folding is a range of robust, top-hung hardware systems for wooden or metal doors weighing up to 35kg, 55kg or 70kg. Ideal for commercial or light industrial application, the system caters for panelled, flush or glazed doors. Doors can fold to one or both sides of the opening or can be stacked behind a reveal if required.

The system covers any width of opening allowing any number of folding doors to be used. Panels should be in units of four, six or eight and can be hinged to post or free floating. For applications where an odd number of doors is required, a swinging access door can be incorporated into a panel which is hinged to post. Alternatively an access door can be independently hinged to post. When the system is fitted externally a canopy is recommended (not supplied by P C Henderson).
