Marathon Fire Rated
Sliding door kit for certified FD30 sliding fire doors weighing up to 90kg
- For use with certified fire doors only
- Certified for 30 minutes of fire protection
| Order Code | Description | Fire Rating | Max. Door Width | Max. Door Height | Door Thickness | To Be Used With | Max Door Weight | Door Material | Application |
|---|---|---|---|---|---|---|---|---|---|
| FDK1 | Self-closing | 30 minutes | 1500mm | 3000mm | 44-50mm | S3, S4, S5 and S6 Kits (Marathon 90) | 90kg | Wood | Interior |
| FDK2 | Non self-closing | 30 minutes | 1500mm | 3000mm | 44-50mm | S3, S4, S5 and S6 Kits (Marathon 90) | 90kg | Wood | Interior |
| Document | Name | File size | |
|---|---|---|---|
|
Marathon Self Closing Fitting Instructions | 275.43 KB | Download |
|
|
Marathon Fire Door Kit - FDK 2 Typical Assembly Booklet | 4.31 MB | Download |
|
|
Marathon Fire Rated Fitting Instructions | 1.35 MB | Download |
|
|
Marathon FDK1 Self-Closing Fitting Instructions | 3.49 MB | Download |
|
|
Marathon Fire Door Kit - FDK 1 Typical Assembly Booklet | 4.71 MB | Download |
|
|
Marathon FDK 2 Non Self-Closing Fitting Instructions | 2.22 MB | Download |
|
|
Marathon Fire Rated Brochure Page | 146.91 KB | Download |
- System should be installed to the non-fire risk side of the aperture
- Two options available – FDK1 (self-closing) and FDK2 (non self-closing)
- Marathon 90 (S3, S4, S5 & S6) kits must be purchased separately (please see optional extras)
Catering for wooden interior doors catering up to 90kg. Marathon Fire Rated is suitable for doors between 750mm and 1500mm wide.
Available in Self Close or Non Self Closing Variants
With two variations available, you can choose between our FDK1 self-closing or FDK2 non selfclosing system. Please consult your Building Inspector prior to purchase to determine if your application requires a self closer.
Certified to FD30 Standards
Assessment report WFRC No. C116602 confirms that a sliding fire door assembly, fitted in accordance with these instructions, will offer 30 minutes of fire protection in accordance with BS476: Part 22: 1987, (ref: report Warres No. 303718). To be used for fire control only, cannot be used for smoke control.
NOTE: A Marathon 90 (S3, S4, S5 or S6) sliding door hardware kit must be used in conjunction with this system
DELIVERY: FDK2 is a made to order item, delivery date will be provided upon order confirmation.
Fire Rated Sliding Door Kit
Marathon Fire Rated is a system developed as part of a 30 minute sliding fire door assembly to BS476: Part 22: 1987 and should be installed on the non-fire risk side of an aperture. The hardware should be fitted with a certified FD30 fire door.
More Information
| Fire Rated (Yes/No) | No |
|---|---|
| Location | Internal |
| Application | Residential |
| Door Material | Wood |
| Fire Rating | FD30 (30 minutes) |
Q&A
Q&A
Question:
Answer:
Question:
Answer:
Unfortunately we do not have a system that could cater for this opening width. The Marathon Fire Rated can not be used with biparting doors.
Thanks,
P C Henderson
Question:
Is it possible to make it pivotal? Do you have mechanisms for this and sell? Otherwise do you thing buşlder can make it?
We need a paintable one. Do you sell paintable ones?
Thanks
Answer:
Is this for a fire rated application? If so, our Marathon Fire Rated is a sliding door system which cannot be modified as this will invalidate the fire rating of the system.
Unfortunately, we do not sell doors, only the hardware system.
Thanks,
P C Henderson
