Evolve Pocket Door Pro (for single and bi-parting doors)
Automated pocket door for wooden sliding doors weighing up to 80kg
- Caters for wooden doors weighing up to 80kg
- 7 different kit sizes (covering doors up to 2315mm x 930mm) for 120mm or 125mm finished wall thickness
| Order Code (120mm Finished Wall Thickness) | Order Code (125mm Finished Wall Thickness) | Track Length | Max Door Width | Max Door Height | Door Thickness Range | Max Door Weight | Door Material | Application |
|---|---|---|---|---|---|---|---|---|
| EVOPRO1/120 | EVOPRO1/125 | 1250mm | 610mm | 1981mm | 35 - 45mm | 80kg | Wood | Interior |
| EVOPRO2/120 | EVOPRO2/125 | 1402mm | 686mm | 1981mm | 35 - 45mm | 80kg | Wood | Interior |
| EVOPRO3/120 | EVOPRO3/125 | 1554mm | 762mm | 1981mm | 35 - 45mm | 80kg | Wood | Interior |
| EVOPRO4/120 | EVOPRO4/125 | 1706mm | 838mm | 1981mm | 35 - 45mm | 80kg | Wood | Interior |
| EVOPRO6/120 | EVOPRO6/125 | 1682mm | 826mm | 2040mm | 35 - 45mm | 80kg | Wood | Interior |
| EVOPRO7/120 | EVOPRO7/125 | 1482mm | 726mm | 2040mm | 35 - 45mm | 80kg | Wood | Interior |
| EVOPRO10/120 | EVOPRO10/125 | 1890mm | 930mm | 2315mm | 35 - 45mm | 80kg | Wood | Interior |
| Document | Name | File size | |
|---|---|---|---|
|
Evolve Pocket Door Pro Datasheet | 361.20 KB | Download |
|
|
Pocket Door Pro Jamb Kit Fitting Instructions | 1.12 MB | Download |
|
|
Evolve Pocket Door Pro Fitting Instructions | 2.09 MB | Download |
|
|
Evolve Motor and Wiring Fitting Instructions | 987.74 KB | Download |
|
|
Evolve Pocket Door Pro Datasheet | 471.96 KB | Download |
|
|
Evolve Pocket Door Pro Datasheet | 165.19 KB | Download |
- Fully automated pocket door system - doors open via control switch, remote control or motion sensor
- Robust aluminium cavity frame with push together parts for rapid installation
- For bi-parting doors, two kits can be purchased
- Kit can be used with or without an architrave - providing the flexibility to create a traditional or modern look
- Jamb kit available as an optional extra for a professional finish
Catering for wooden doors weighing up to 80kg, Evolve Pocket Door Pro offers a professional sliding door solution for automated pocket doors.
Biparting Doors
For double automated pocket door applications, two kits can be purchased.
Rapid installation
The system has been designed with a high quality aluminium cavity frame and push together parts to allow for easy and rapid installation. Watch our easy-to-follow installation video at the bottom of the page.
Accessories
The systems comes with two wall mounted control panels as standard or the kit can be upgraded with an optional remote control kit or motion sensor. A timber jamb kit is also available for ease of installation to create a professional finish.
Wide Range of Applications
Catering for residential and light commercial applications, Evolve Pocket Door Pro has many space saving benefits making it ideal for rooms where interior space is limited such as bathrooms, ensuites or kitchens. When open, the doors automatically slide into a cavity wall, leaving the area clear of obstruction and increasing valuable floor space.
Seven Kit Sizes Available
The system is available in seven different kit sizes, which can also be reduced in both width and height to cater for non standard doors sizes. The kit can also be installed with or without an architrave – providing the flexibility to create a traditional or modern look.
Door Activation
Sliding doors can open at the push of a button, remote control or by activation of a movement sensor – offering the utmost in sophistication and convenience.
More Information
| Fire Rated (Yes/No) | No |
|---|
