Straight Sliding 290, 301, 305, 307

Industrial sliding door gear for wooden and metal doors weighing between 150kg and 2000kg

  • Seven systems available to cater for a variety of different door weights
  • Widely used in heavy and large industrial applications
SKU:
straight-sliding-290-301-301h-305-and-307

Contact a member of our sales team to enquire about this product

main product photo
Product Information
Product Door Thickness RangeDoor MaterialApplicationMax Door Weight
Straight Sliding 29035 - 48mmWood/MetalInterior/Exterior200kg (150kg if using nylon hangers)
Straight Sliding 301 43 - 57mmWood/MetalInterior/Exterior400kg
Straight Sliding 301H43 - 57mmWood/MetalInterior/Exterior450kg
Straight Sliding 30543 - 57mmWood/MetalInterior/Exterior700kg
Straight Sliding 30760 - 70mmWood/MetalInterior/Exterior2000kg
Attachments
Document Name File size PDF
PDF icon Flushbolt 78 Fitting Instructions 41.45 KB Download
PDF icon Flushbolt 77 Fitting Instructions 37.33 KB Download
PDF icon Aluminium Bolt 454 Fitting Instructions 66.93 KB Download
PDF icon Aluminium Bolt 333 Fitting Instructions 66.77 KB Download
PDF icon P C Henderson Case Study - Straight Sliding - NECC Hotel Shanghai 875.81 KB Download
PDF icon Industrial Components Datasheet 2.98 MB Download
PDF icon Straight Sliding 290 Datasheet 631.44 KB Download
PDF icon P C Henderson Case Study - Straight Sliding 301 - Unique Boat House 2.43 MB Download
PDF icon Straight Sliding 301 Datasheet 625.61 KB Download
PDF icon Straight Sliding 305 Datasheet 893.37 KB Download
PDF icon Straight Sliding 307 Datasheet 876.91 KB Download
PDF icon P C Henderson Case Study - Straight Sliding 307 - Shanghair Disneyland 3.52 MB Download
PDF icon P C Henderson Case Study - Straight Sliding 307 - Skandavale Monestry 755.42 KB Download
Description PDF DXF DWG
89 - CHANNEL LVL A
89 - CHANNEL LVL A 45.38 KB 293.96 KB 251.04 KB
94X - CHANNEL LVL A
94X - CHANNEL LVL A 55.71 KB 294.59 KB 150.17 KB
1 290S - BRACKET LVL A
1 290S - BRACKET LVL A 57.29 KB 407.18 KB 281.07 KB
1 301S - BRACKET LVL A
1 301S - BRACKET LVL A 53.72 KB 369.71 KB 270.45 KB
100 - CHANNEL LVL A
100 - CHANNEL LVL A 44.73 KB 295.09 KB 251.38 KB
102 97 - GUIDE LVL A
102 97 - GUIDE LVL A 60.61 KB 564.84 KB 318.77 KB
104P 89 - GUIDE LVL B
104P 89 - GUIDE LVL B 114.41 KB 539.68 KB 692.60 KB
104P 97 - GUIDE LVL A
104P 97 - GUIDE LVL A 68.23 KB 1.17 MB 482.33 KB
104PX 89 - GUIDE LVL A
104PX 89 - GUIDE LVL A 55.10 KB 456.77 KB 293.11 KB
104PX 97 - GUIDE LVL A
104PX 97 - GUIDE LVL A 72.98 KB 1.21 MB 349.70 KB
105R 89 - GUIDE LVL A
105R 89 - GUIDE LVL A 49.50 KB 326.35 KB 259.88 KB
105R 97 - GUIDE LVL A
105R 97 - GUIDE LVL A 57.80 KB 325.39 KB 259.89 KB
106R 97 - GUIDE LVL A
106R 97 - GUIDE LVL A 50.90 KB 315.30 KB 256.94 KB
107 - STOP LVL A
107 - STOP LVL A 42.80 KB 333.96 KB 110.45 KB
107E Buffer Stop LVLB
107E Buffer Stop LVLB 97.19 KB 568.63 KB 772.70 KB
109 - STOP LVL A
109 - STOP LVL A 53.91 KB 342.20 KB 264.04 KB
126 - GUIDE LVL A
126 - GUIDE LVL A 57.25 KB 484.25 KB 300.39 KB
126H - GUIDE LVL A
126H - GUIDE LVL A 60.63 KB 268.61 KB
126HD A - GUIDE LVL A
126HD A - GUIDE LVL A 90.29 KB 530.05 KB 267.40 KB
128 - GUIDE LVL A
128 - GUIDE LVL A 142.52 KB 4.52 MB 1.33 MB
1A 290 - BRACKET LVL B
1A 290 - BRACKET LVL B 108.90 KB 155.27 KB
1A 290EC - END CLIP LVL A
1A 290EC - END CLIP LVL A 49.02 KB 359.85 KB 269.00 KB
1A 301 - BRACKET LVL A
1A 301 - BRACKET LVL A 57.27 KB 430.05 KB 285.79 KB
1A 301EC - ENDCLIP LVL A
1A 301EC - ENDCLIP LVL A 51.78 KB 332.52 KB 260.84 KB
1A 305 - BRACKET LVL A
1A 305 - BRACKET LVL A 58.39 KB 363.60 KB 269.37 KB
290 - STRAIGHT SLIDING DOUBLE RUN STEEL LVL A
290 - STRAIGHT SLIDING DOUBLE RUN STEEL LVL A 81.09 KB 877.60 KB 289.86 KB
290 - STRAIGHT SLIDING DOUBLE RUN TIMBER LVL A
290 - STRAIGHT SLIDING DOUBLE RUN TIMBER LVL A 83.99 KB 876.09 KB 287.21 KB
290 - STRAIGHT SLIDING SINGLE RUN STEEL LVL A
290 - STRAIGHT SLIDING SINGLE RUN STEEL LVL A 72.77 KB 856.87 KB 285.33 KB
290 - STRAIGHT SLIDING SINGLE RUN TIMBER LVL A
290 - STRAIGHT SLIDING SINGLE RUN TIMBER LVL A 79.20 KB 987.56 KB 319.27 KB
290 - TRACK LVL A
290 - TRACK LVL A 46.50 KB 325.05 KB 258.13 KB
3 301S - BRACKET LVL A
3 301S - BRACKET LVL A 58.00 KB 395.89 KB 276.89 KB
301 - TRACK LVL A
301 - TRACK LVL A 116.14 KB 748.66 KB
301(H) - STRAIGHT SLIDING DOUBLE RUN STEEL LVL A
301(H) - STRAIGHT SLIDING DOUBLE RUN STEEL LVL A 108.40 KB 1.13 MB 355.43 KB
301(H) - STRAIGHT SLIDING DOUBLE RUN TIMBER LVL A
301(H) - STRAIGHT SLIDING DOUBLE RUN TIMBER LVL A 121.77 KB 1.33 MB 415.61 KB
301(H) - STRAIGHT SLIDING SINGLE RUN STEEL LVL A
301(H) - STRAIGHT SLIDING SINGLE RUN STEEL LVL A 82.83 KB 1.20 MB 392.04 KB
301(H) - STRAIGHT SLIDING SINGLE RUN TIMBER LVL A
301(H) - STRAIGHT SLIDING SINGLE RUN TIMBER LVL A 99.21 KB 1.43 MB 434.42 KB
301H - TRACK LVL A
301H - TRACK LVL A 44.64 KB 334.94 KB 254.59 KB
305 - STRAIGHT SLIDING DOUBLE RUN STEEL LVL A
305 - STRAIGHT SLIDING DOUBLE RUN STEEL LVL A 123.71 KB 1.19 MB 371.67 KB
305 - STRAIGHT SLIDING DOUBLE RUN TIMBER LVL A
305 - STRAIGHT SLIDING DOUBLE RUN TIMBER LVL A 105.10 KB 1020.00 KB 316.98 KB
305 - STRAIGHT SLIDING SINGLE RUN STEEL LVL A
305 - STRAIGHT SLIDING SINGLE RUN STEEL LVL A 100.96 KB 1.12 MB 358.65 KB
305 - STRAIGHT SLIDING SINGLE RUN TIMBER LVL A
305 - STRAIGHT SLIDING SINGLE RUN TIMBER LVL A 92.08 KB 971.72 KB 306.01 KB
305 -TRACK LVL A
305 -TRACK LVL A 45.23 KB 292.50 KB 250.69 KB
307 - STRAIGHT SLIDING DOUBLE RUN STEEL LVL A
307 - STRAIGHT SLIDING DOUBLE RUN STEEL LVL A 91.16 KB 1.07 MB 335.60 KB
307 - STRAIGHT SLIDING DOUBLE RUN TIMBER LVL A
307 - STRAIGHT SLIDING DOUBLE RUN TIMBER LVL A 110.11 KB 1.63 MB 491.69 KB
307 - STRAIGHT SLIDING SINGLE RUN STEEL LVL A
307 - STRAIGHT SLIDING SINGLE RUN STEEL LVL A 53.50 KB 1.07 MB 335.03 KB
307 - STRAIGHT SLIDING SINGLE RUN TIMBER LVL A
307 - STRAIGHT SLIDING SINGLE RUN TIMBER LVL A 92.28 KB 953.13 KB 300.56 KB
307 - TRACK LVL A
307 - TRACK LVL A 48.15 KB 285.87 KB 248.92 KB
31D - GUIDE LVL A
31D - GUIDE LVL A 71.49 KB 1.37 MB 533.83 KB
31S - GUIDE LVL A
31S - GUIDE LVL A 63.69 KB 1.03 MB 443.60 KB
3A 290 - BRACKET LVL A
3A 290 - BRACKET LVL A 22.35 KB 311.55 KB 99.01 KB
3A 301 - BRACKET LVL A
3A 301 - BRACKET LVL A 58.43 KB 363.48 KB 269.15 KB
3A 305 - BRACKET LVL B
3A 305 - BRACKET LVL B 85.25 KB 585.48 KB 958.61 KB
3AX 305 - BRACKET LVL A
3AX 305 - BRACKET LVL A 342.49 KB 343.39 KB
3X 301S SOFFIT FIX JOINTING BRACKET LVL A
3X 301S SOFFIT FIX JOINTING BRACKET LVL A 84.05 KB 593.99 KB 388.92 KB
4 301S - HANGER LVL A
4 301S - HANGER LVL A 62.61 KB 602.65 KB 331.03 KB
4A 301 - BRACKET LVL A
4A 301 - BRACKET LVL A 57.89 KB 428.44 KB 285.42 KB
4A 305 - BRACKET LVL A
4A 305 - BRACKET LVL A 59.16 KB 443.79 KB 289.25 KB
4AX 301 - BRACKET LVL B
4AX 301 - BRACKET LVL B 89.88 KB 559.89 KB 751.83 KB
4AX 305 - BRACKET LVL A
4AX 305 - BRACKET LVL A 370.55 KB 312.14 KB
4R 290S - BRACKET LVL B
4R 290S - BRACKET LVL B 104.04 KB 152.58 KB
4R 290SB - BRACKET LVL A
4R 290SB - BRACKET LVL A 51.17 KB 311.93 KB 255.82 KB
4R 301S - HANGER LVL A
4R 301S - HANGER LVL A 62.36 KB 728.92 KB 362.26 KB
4R 307S - BRACKET LVL A
4R 307S - BRACKET LVL A 65.62 KB 834.59 KB 390.89 KB
4R 307SB - BRACKET LVL A
4R 307SB - BRACKET LVL A 54.63 KB 308.94 KB 255.38 KB
4RX 301TS - BRACKET LVL A
4RX 301TS - BRACKET LVL A 57.44 KB 528.06 KB 311.08 KB
4RX 307S - BRACKET LVL A
4RX 307S - BRACKET LVL A 97.65 KB 251.06 KB
4X 301S SOFFIT FIX JOINTING BRACKET LVL A
4X 301S SOFFIT FIX JOINTING BRACKET LVL A 82.07 KB 709.52 KB 419.60 KB
5 290 - BRACKET LVL A
5 290 - BRACKET LVL A 109.04 KB 151.73 KB
52A - HANGER LVL A
52A - HANGER LVL A 76.24 KB 982.68 KB 427.09 KB
52C - HANGER LVL A
52C - HANGER LVL A 72.02 KB 840.75 KB 391.97 KB
53A - HANGER LVL A
53A - HANGER LVL A 73.81 KB 989.80 KB 429.13 KB
53A_N LEVEL A
53A_N LEVEL A 141.31 KB 186.52 KB
53C - HANGER LVL A
53C - HANGER LVL A 77.54 KB 955.57 KB 420.70 KB
53FJ - HANGER LVL A
53FJ - HANGER LVL A 76.52 KB 909.49 KB 408.46 KB
53K - HANGER LVL A
53K - HANGER LVL A 63.68 KB 540.11 KB 315.25 KB
53K_N_LEVEL A
53K_N_LEVEL A 153.39 KB 181.21 KB
56,5K - HANGER LVL A
56,5K - HANGER LVL A 69.33 KB 1.00 MB 437.56 KB
56AF - HANGER LVL A
56AF - HANGER LVL A 68.23 KB 742.48 KB 366.18 KB
56AX - HANGER LVL A
56AX - HANGER LVL A 63.54 KB 552.22 KB 320.41 KB
56C - HANGER LVL A
56C - HANGER LVL A 77.72 KB 1.30 MB 513.33 KB
56CF - HANGER LVL A
56CF - HANGER LVL A 67.17 KB 706.66 KB 357.15 KB
56CX - HANGER LVL A
56CX - HANGER LVL A 75.89 KB 1.36 MB 529.92 KB
56FJ - HANGER LVL B
56FJ - HANGER LVL B 90.88 KB 655.62 KB 783.71 KB
56FJX - HANGER LVL B
56FJX - HANGER LVL B 98.43 KB 1.24 MB 896.97 KB
56KX - HANGER LVL A
56KX - HANGER LVL A 60.95 KB 531.70 KB 314.61 KB
57A - HANGER LVL A
57A - HANGER LVL A 64.91 KB 494.51 KB 304.15 KB
57C - HANGER LVL A
57C - HANGER LVL A 64.83 KB 631.26 KB 339.05 KB
6 301S - BRACKET LVL A
6 301S - BRACKET LVL A 45.87 KB 298.45 KB
9 301S - BRACKET LVL A
9 301S - BRACKET LVL A 49.97 KB 372.06 KB 270.96 KB
9 307S - BRACKET LVL A
9 307S - BRACKET LVL A 59.45 KB 351.39 KB 266.09 KB
94 - CHANNEL LVL A
94 - CHANNEL LVL A 44.23 KB 293.64 KB 250.93 KB
97 - CHANNEL LVL A
97 - CHANNEL LVL A 44.89 KB 294.85 KB 251.70 KB
9A 305 - BRACKET LVL A
9A 305 - BRACKET LVL A 55.19 KB 356.44 KB 267.53 KB
9A_305LC
9A_305LC 127.63 KB 147.42 KB
HH3 290 - STOP LVL A
HH3 290 - STOP LVL A 52.86 KB 385.33 KB 274.63 KB
HH3 301 - STOP LVL A
HH3 301 - STOP LVL A 56.04 KB 514.34 KB 307.83 KB

Industrial sliding door gear for wooden and metal doors weighting between 150kg and 2000kg

  • Seven systems available to cater for a variety of different door weights
  • Widely used in heavy and large industrial applications
  • Can cover any width of opening using any number of doors on single or multiple lines of track
  • Specified as individual components to accommodate for different building designs
  • Doors can slide to one or both sides of the opening
  • Wicket door for easy access may be incorporated into a sliding door

Versatile Industrial Sliding Door Gear

Specified as individual components, Straight Sliding offers a versatile sliding door system to accommodate different building designs. Doors can slide to one or both slides and are also suitable to cover any width of opening.

Seven Systems Available

Straight Sliding offers a range of industrial sliding door gear to allow for the easy movement of anything from light commercial doors up to very heavy and large industrial applications. Suitable for wooden and metal doors, the range includes seven systems to cater for doors weighing up to an impressive 2000kg.

More Information

More Information
Fire Rated (Yes/No) No
Door Material Wood or Metal
Situation Exterior
Application Industrial

Q&A

Q&A

Show more

Question:

what size track for 1000kg barn door
Question by: tim heal on 6 Sep 2024, 12:05

Answer:

Good morning,

For a 1000kg door we would recommend our Straight Sliding 307 system and track.

Many thanks,
P C Henderson
Answer by: Kate Donkin (Admin) on 9 Sep 2024, 08:51
